In steel structure manufacturing, H-beams often require multi-angle rotating during processes such as welding, painting and assembly. Traditional manual or simple lifting methods are not only inefficient but also pose significant safety hazards. Our crane rotator device is a material turning machine designed specifically for heavy workpieces, typically used in conjunction with overhead cranes. Its core function is to achieve stable turning, precise positioning, multi-angle control of H-beams while ensuring stability and safety.
H-Beam Rotating Operation Process
Connect the crane hook to the turning device → Secure the H-beam with the sling → Lift to a safe height → Activate the turning system → Rotating the H-beam smoothly → Stop at the specified angle → Perform welding, painting, or assembly operations
Structure of the Crane Rotator Device
Load-bearing beam: Bears the overall load and ensures structural rigidity
Electric turning mechanism: Consists of a motor, reducer and transmission components to perform the rotating action
Lifting slings: High strength composite fiber belt slings used to secure steel structures and prevent damage during rotating
Electrical control system: Controls turning speed and direction for precise operation
Safety protection devices: Including limit switches, braking systems and overload protection modules
Connecting components: For attachment to crane hooks or lifting beams
Technical Features of the Crane Rotator Device
Manufactured from high quality alloy steel with excellent bending and torsional resistance, capable of handling heavy-duty H-beam rotating.
Synchronized turning control system ensures synchronized movement of load points during rotating, effectively preventing workpiece deformation or tilting.
Supports 0° - 360° rotation control with arbitrary angle positioning to meet process requirements and improve operational accuracy.
Customizable design based on H-beam specifications (length, width, weight) and working space to suit various industrial scenarios.
Key Selection Criteria
Rated load capacity (1T - 50T)
H-beam size range
Rotating angle and speed
Drive type (electric)
Control method (remote control / PLC automation)
Installation type (for single girder / double girder cranes)
Choosing high performance, customizable turning device can significantly improve production efficiency while effectively reducing safety risks and operating costs. If you are looking for a suitable heavy duty load turning solution, please feel free to contact us for professional technical support and product quotation.
